AWM 403

Immerse yourself in audio excellence with the Audibax AWM 403, a four-channel wireless microphone with UHF modulation, precisely designed to provide a unique sound experience.

This high-tech receiver features three frequency options and a 2X32MHz bandwidth, ensuring versatility and adaptability in different environments.

With ±45 KHz compensation capability, the receiver dynamically adjusts for accurate sound reproduction. A signal-to-noise ratio of over 105dB(A) and distortion of less than 0.3% at 1 KHz ensure exceptional audio quality.

Designed to cope with diverse conditions, it operates in a temperature range from -10°C to 55°C and offers an impressive working distance of up to 100 meters in ideal environments.

The Audibax AWM 403 incorporates four pocket transmitters with maximum precision RF output power. They use a PLL oscillation mode with digital frequency synthesizer to ensure stable transmission. With a transmit frequency stability of less than 30ppm, an impressive dynamic range of ≥100dB (A) and frequency response from 50Hz to 15KHz, the condenser microphones with headset microphone format capture your sound authentically and allowing absolute mobility. Maximum input pressure of 130dB SPL ensures powerful performance. Powered by 2 AA alkaline batteries, this system provides long-lasting, high-performance operation.

The Audibax AWM 403 is the perfect choice for those seeking exceptional audio quality and wireless reliability. Designed especially for situations where freedom of movement is essential, such as stage presentations or live events, this system lets you discover a new standard in sound performance with Audibax.

Receiver:

• 640MHz to 690MHz frequency range.
• Band adjustment of 2X32MHz.
• Advanced UHF modulation technology.
• Frequency compensation capability of ±45 KHz.
• Signal-to-noise ratio exceeding 105dB(A).
• Distortion less than 0.3% at 1 KHz.
• Temperature range from -10°C to 55°C.
• Working distance up to 100 meters in an ideal environment.

Microphone/Transmitter (4 pcs):

• 4 pcs.
• Highest precision RF output power.
• Mini-XLR connector
• PLL oscillation mode for stable and uninterrupted transmission.
• Transmit frequency stability of less than 30 ppm.
• Dynamic range of ≥100dB (A).
• Frequency response from 50Hz to 15KHz.
• Maximum input sound pressure of 130 dB SPL.
• Built-in microphone with moving coil pickup.
