AWM 401 TD

Experience exceptional sound performance with the Audibax AWM 401 TD, a complete wireless system that elevates your listening experience. Equipped with a state-of-the-art receiver and four handheld transmitters, this system offers a comprehensive solution to ensure a stable and powerful transmission of your voice and sound.

The high-tech receiver operates with precision thanks to its PLL (digital frequency synthesizer) oscillation mode, ensuring stable and interference-free transmission. Its 5dBuV sensitivity allows it to pick up weak signals with clarity. In addition, it offers balanced and unbalanced output options for versatile connectivity.

Each of the four handheld transmitters with maximum precision RF output power. PLL oscillation mode and transmit frequency stability of less than 30 ppm ensure accurate, clipping-free transmission. With an exceptional dynamic range of ≥100dB (A) and a frequency response of 50Hz-15KHz, these transmitters capture every nuance of your voice. Equipped with dynamic microphones, they offer a maximum input pressure of 130dB SPL for powerful, authentic performance.

Powered by 2 AA batteries, the transmitters offer unrestricted mobility. The receiver, efficient with a voltage of 12-16V and working current ≤350mA, completes this high performance wireless system. The Audibax AWM 401 TD is the ideal choice for live events, providing an exceptional sound experience on any stage.

Receiver:

• Oscillation mode: PLL (digital frequency synthesizer).
• Frequency response: 50Hz-15KHz
• Sensitivity: 5dBuV.
• Balanced output (XLR connector): 250 mV/600 Ω.
• Unbalanced output (1/4″ connector): 400 mV/K3.
• Operating voltage: DC 12-16 V.
• Operating current: ≤350mA.

Handheld Transmitter:

• Maximum precision RF output power.
• Oscillation mode: PLL (digital frequency synthesizer).
• Transmitting frequency stability: <30 ppm.
• Dynamic range: ≥100dB (A).
• Frequency response: 50Hz-15KHz.
• Maximum input pressure: 130dB SPL.
• Microphone: Dynamic.
• Power supply: 2 AA alkaline batteries (1.5V).
